Tiv tauj peb kom paub ntau ntxiv ISUZU C240 Cav Qhov Chaw!
Cov ntsiab lus
Nov yog peb cov yeeb yaj kiab YouTube!
Thaum nws los txog rau lub zog forklifts, tshwj xeeb tshaj yog rau cov ntawv thov kev lag luam, Isuzu C240 cav tawm los ua tus neeg sib tw sab saum toj. Tab sis dab tsi tiag tiag ua rau lub cav no yog qhov kev xaiv zoo tshaj plaws rau HELI 3T forklifts? Cov lus teb yog nyob rau hauv nws cov qauv tsim, txhim khu kev qha kev ua tau zoo, thiab cov thev naus laus zis siab heev uas haum rau cov kev xav tau ntawm HELI forklifts.
Specifications ntawm Isuzu C240 Cav
| Tsis muaj | Specification |
|
Kev khiav tawm |
2.369L |
|
Number ntawm lub tog raj kheej |
4 |
|
Npog x Stroke |
86 hli x 102 hli |
|
Intake Method |
Ntuj Aspirated |
|
Txoj kev txhaj tshuaj |
Kev txhaj tshuaj tsis ncaj |
|
Hom roj |
Diesel |
|
Net nyhav |
252kg ua |
|
Emission Txuj |
National III |
|
Cov zis siab tshaj plaws |
35.4KW (2500r / min) |
|
Maximum Torque |
320 Nm (1800r / min) |
|
Qhov ntev |
693mm x 551mm x 689mm |
Technical Advantage
VGS Variable Geometry Turbocharging Technology
Forklift Isuzu C240 Cav nta VGS thev naus laus zis, ua kom nws xa lub zog siab tshaj plaws ntawm 320Nm ntawm 1800 RPM xwb. Qhov no yog ib qho tseem ceeb heev rau kev tswj kom muaj zog traction thiab lifting peev xwm nyob rau hauv forklifts, tshwj xeeb tshaj yog nyob rau hauv qis-ceev tej yam kev mob uas feem ntau pib, nce toj, thiab load-khiav hauj lwm.
Ddi Supercharged Common Rail Technology
Nrog rau kev txhaj tshuaj siab txog li 180 MPa, cov thev naus laus zis no ua kom cov roj atomization zoo heev thiab ua kom tiav combustion. Muab piv rau cov roj av cav ntawm qhov kev hloov pauv zoo sib xws, Isuzu C240 lub cav txo cov roj noj los ntawm 20% -30%. Rau cov neeg siv, qhov no txhais ua haujlwm tseem ceeb ntawm kev txuag nqi.
Kev Ua Haujlwm Zoo
High Fuel Efficiency
Isuzu C240 Diesel Cav muaj npe nrov rau nws cov khoom siv zoo thiab cov txheej txheem tsim khoom nruj, ua kom muaj kev ntseeg tau ntev thiab ua haujlwm ntev. Qhov no ua rau nws zoo tagnrho rau kev ua haujlwm tas mus li thiab ntev, tshwj xeeb yog qhov tseem ceeb hauv kev lag luam thiab kev lag luam kev lag luam uas qhov ua tau zoo yog qhov tseem ceeb.
01
Environmental Compliance thiab Friendliness
Lub cav Isuzu C240 ua tau raws li Tuam Tshoj theem III emission cov qauv, siv cov emission tswj technologies siab heev los txo cov pa phem. Nws yog ib puag ncig tus phooj ywg thiab ua raws li kev cai lag luam thoob ntiaj teb, ua rau nws hloov tau mus rau thaj chaw sib txawv.
02
High Reliability thiab Durability
Isuzu forklift engine yog tsim los nrog cov khoom hwm zoo thiab ua raws li cov qauv tsim khoom nruj, ua kom nws ruaj khov hauv kev xav tau ib puag ncig. Qhov no txo cov kev xav tau ntawm kev saib xyuas thiab txo qis qis qis, uas yog qhov tseem ceeb rau kev ua haujlwm forklift hauv cov xwm txheej hnyav.
03
Lub teeb thiab compact tsim
Txawm hais tias nws cov qauv tsim compact thiab lub teeb, lub cav C240 muab lub zog siab tshaj plaws ntawm 35.4KW. Qhov kev tsim no tso cai rau cov forklifts nyob twj ywm tsis muaj zog ntau dua thiab ua haujlwm tau zoo.
04
Kev thov dav
Lub cav Isuzu C240 tsis yog tsuas yog haum rau Heli 1-3T sab hauv combustion forklifts tab sis kuj tau siv dav hauv lwm cov khoom siv hauv kev lag luam, ua pov thawj nws yoog raws thiab kev ruaj ntseg thoob plaws ntau yam kev nyuaj.
05
Kev tswj xyuas qhov ua tau zoo ntawm koj lub cav Isuzu forklift yuav tsum tau nkag mus rau qhov chaw zoo. Yog li, qhov twg koj tuaj yeem nrhiav kev ntseeg siab Isuzu C240 cav qhov chaw? Peb lub tuam txhab muaj kev xaiv ntau yam ntawm cov khoom tiag, kom ntseeg tau tias koj muaj txhua yam koj xav tau kom koj lub cav khiav zoo. Nrog rau peb cov khoom muag ntau thiab xa khoom sai, koj tuaj yeem suav rau peb los muab cov khoom koj xav tau thaum koj xav tau.
Peb muab cov khoom siv phau ntawv qhia rau Isuzu C240 lub cav, nrog rau cov ntawv teev npe rau qee yam ntawm peb cov khoom. Nco ntsoov mus download tau lawv tam sim no!
Cov tsos mob thaum ntxov
Lub zog tseem ceeb poob qis
Lub cav lub zog ua haujlwm tau pom zoo txo qis.
Cold Start nyuaj
Lub cav tawm tsam pib, tshwj xeeb tshaj yog nyob rau hauv txias txias.
Severe Crankcase Blow-by
Cov pa ntau dhau los ntawm lub tshuab pa tawm los ntawm crankcase breather.
Cov pa luam yeeb dub los ntawm Exhaust
Cov pa tawm tawm cov pa luam yeeb dub thaum lub sijhawm ua haujlwm siab.
Cov cim qhia ntawm C240 Cav Hnav
Hnyav Piston Ring Wear
Cov piston rings qhia qhov hnav tseem ceeb, nrog qhov sib txawv ntawm lub nplhaib compression feem ntau ncav cuag qhov txwv ntawm 2 hli.
Lub tog raj kheej Liner Hnav
Ib daim ntaub ntawv ntawm qhov chaw tuag saum toj kawg nkaus, nrog hnav tshaj qhov siab tshaj plaws clearance. Sab nraud discoloration thiab sab hauv deterioration ntawm chrome plating, nrog rau cov cim ntawm kev sib txhuam qhuav vim roj depletion, yog pov thawj.
Yog vim li cas rau C240 Cav Hnav
Cov txheej txheem tawg tsis raug
Tsis ua raws li cov chaw tsim khoom tawg-hauv thiab kev siv cov lus qhia thaum pib lub cav tshiab.
Pib nquag
Tshwj xeeb tshaj yog nyob rau hauv cov mob khaub thuas, cia li load nce tom qab pib nyob rau hauv qis kub ua rau ua ntej txhua yam hnav.
Kev tu thiab kev siv tsis raug
Kev saib xyuas tsis txaus thiab kev siv tsis raug ua rau muaj kev ua kom lub cev muaj zog.
5. Yuav Ua Li Cas Tiv Thaiv Thaum Ntxov Hnav hauv Isuzu C240 Cav?
- Ua raws li Cov Txheej Txheem Ua Haujlwm Zoo: Lub cav yuav tsum tau kuaj xyuas thiab tawg ua ntej ua zaub mov xa tuaj, thiab yuav tsum tau tawg ntxiv tom qab kev teeb tsa. Rau lub cav C240 diesel hauv Heli forklifts, lub sijhawm tawg yog 50-100 teev. Cov theem no txhim kho qhov zoo ntawm kev sib txhuam ntawm qhov chaw.
-
Tswj Kev Hnav Thaum Ntxov: Thaum lub sijhawm tawg, cov khoom muaj qhov ntxhib thiab ua rau muaj kev sib koom tes sai dua. Detached hlau lossis oxides tuaj yeem ua rau muaj kev puas tsuaj loj. Txhawm rau txo qhov no, ua raws li kev txwv ceev thiab thauj khoom, hloov cov roj, thiab tswj xyuas qhov kub thiab txias ua haujlwm (qhov txias txias ntawm 80-90 degree ) thiab roj siab. Tsis txhob maj nrawm kom txo qis hnav thaum ntxov thiab txuas ntxiv lub neej.
Ua raws li cov txheej txheem ua haujlwm kom raug: Ib txwm ua kom lub cav ua ntej, pib maj mam, tsis ua haujlwm kom sov, thiab pib ua haujlwm ntawm qhov nrawm. Khaws qhov kub thiab txias ua haujlwm nruab nrab.
- Air Filter: Cov lim cua ua rau muaj kev cuam tshuam rau lub cav ntev. Kev pom tsis zoo los yog cov ntsaws ruaj ruaj tsis zoo tuaj yeem tso cov plua plav mus rau hauv lub tog raj kheej, ua kom nrawm nrawm ntawm cov khoom xws li lub tog raj kheej liner thiab piston rings. Nyob rau hauv ib puag ncig muaj kuab heev, siv lub tshuab lim cua sib xyaw.
- Roj Lim: Kev saib xyuas tsis tu ncua ntawm cov roj lim yog qhov tseem ceeb. Rau cov forklifts ua haujlwm hnyav, hloov cov roj thiab ntxuav lossis hloov cov roj lim txhua 2-3 lub hlis lossis tom qab kwv yees li 150 teev ua haujlwm.
- Xaiv Cov Roj Zoo: Xaiv cov roj nplua nyeem uas muaj cov viscosity siab dua me ntsis los yog cov uas tsis tshua muaj kev cuam tshuam los ntawm qhov kub thiab txias los tswj kev pib nquag thiab cov khoom siv siab.
- Ua raws li Tuam Tshoj cov lus pom zoo: Siv cov roj nplua nyeem uas ua tau raws li cov neeg tsim khoom tshwj xeeb. Nyob rau hauv cov xwm txheej uas nquag pib txias los yog muaj kev hloov pauv tseem ceeb, xaiv cov roj nplua nyeem qib siab.
